*Haltech Ecu not included*
The VMR Converter Box was designed to solve the lack of communication between standalone engine management systems and your factory vehicle equipment such as your body control module and instrument cluster.
This kit will allow you to completely remove the OEM ECU from your Civic and be replaced with a full Standalone while keeping all the OEM functionality + added features.
Currently in testing, all functions work.
Purchases now will get you into early access
The item listed may not comply with local or federal emission regulations. These products are intended solely for off-road use or sanctioned racing events. It is the responsibility of the user to ensure that these products are used in accordance with all applicable laws and regulations. If a product was purchased in error, do not install or use it.
The optional 6' harness is configured as follows:
-
2-pin DTM (Boost Control) – Engine Bay
-
6-pin DTM (Gateway) – Near Haltech
-
8-pin DTM (Remaining I/O) – Engine Bay
Our adapters are assembled here in USA with quality parts
Installation is simple, and generally can be installed in 20 minutes or less
2006 - 2011 Honda Civic EX/LX/SI
- Speedometer
- Odometer
- A/C
- CEL set by Haltech
- Cruise Control
- All 4 Wheel Speed Sensors
- VSA button input
- ABS/EPS receiving data
Haltech Notes:
Some functions are emulated as IO 12 Expander Box B
Warranty Information:
1 Year
Damage due to improper installation is not covered, please follow installation instructions. If you have any questions at all about the install process, please contact your supplying dealer.
Note: This hardware does not come with any basemaps, and will not function whatsoever without being tuned.
